Cloning How To-Tutorial

Posted: Sun, 22nd Mar 2009, 9:20pm

Post 1 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Rating: +1

Cloning Tutorial
Introduction
Cloning is a very cool, very useful, and very practical video effect. I have used the cloning technique countless times in my movies, and have always found it to be successful. This tutorial will walk you through the steps of the cloning technique, and should help to give you a better understanding of how to use it!
This tutorial will cover the effect in Adobe Premier Elements and I will add the tutorial for FX Home Composite Lab Pro For the Premier tutorial, this will be basically the same for other NLEs as well. There will be some variability, but not too much.
Materials
-An NLE (editing software)

-A computer

-An actor/actress/pet [this tutorial uses a dog to show the effect but the same thing can be done with a person.
-A video camera

-A tripod (an absolute must)

Getting started
Okay, well now that we’ve gathered the materials, I will begin to walk you through the cloning process.
1.You need to find a suitable location to film the effect. Make sure it is in a low traffic area so no one interrupts the shot. For this first time, we will do the effect indoors, although it is very possible for an outside effect.
2.Setting up the camera and tripod. This is the most important step as this needs to be precise. The tiniest camera movement will completely mess the shot up.
3.Get you actor/actress/pet ready for the shot and on screen.
4.Record the video. The best thing to do is to press start and let the camera run until the end of the filming portion of the effect. This is best as you will not accidentally disturb the camera’s position by pressing the record button and will leave the shot steady. (of course, if your camera has a remote control, this is a good alternative option.
5.For this tutorial we moved the subject (the dog) around into 3 different areas of the shot (note: we did not move the camera, just the dog)
6.After the filming is done and you got all the positions you want (again, recorded into 1 scene), press the stop button on the camera.
7.Import the video footage into the NLE (editing software)

The raw footage of our video is available here
8.Drag the video clip into the timeline

9.If you want to, now is a good time to delete the source audio (this can be accomplished by right-clicking the video in the timeline and selecting delete audio

10.Now we want to make the cuts in the video we filmed to make it into 3 different scenes with the dog in a different position in each one. We will also eliminate the un-needed video as well.

Okay, now the trickier part:
1.Drag each of the 3 clips that were made into video 1, video 2, and video 3 sections under the timeline view:

2.Now we need to select clip 1 and cut the video edges off that we don’t need using the crop tool:

Basically, you want to play around with the crop tool to cut the bottom, top, left and right sides of the clips until the three dogs are visible. This is because the video on top hides the one under it which hides the third video under that one. Basically, you are pealing back layers with the crop tool but leaving the edited one visible as well.
3.Repeat the above process for videos 1-3. Be sure the lighting matches in all 3, if not you can adjust it under the image control settings.

Also, make sure the videos line up—if not, the scene will need to be re-filmed as the camera moved.
4.Once the videos line up and all 3 dog clones (or subject clones) are visible, it is time to export the file.
a.You can choose from a variety of files types in premier and basically any other program.


The final video clip of the cloning effect is available here I hope that someone finds the tutorial to be helpful. I know that cloning is one of my favorite effects and thought I could share some of my knowledge with others. I will update the tutorial later with the Composite Lab tutorial on cloning. It should be ready sometime tomorrow or Monday.

P.S. I also wanted to add this link to a video I did a while back with cvloning my dog: cloning/disappearing dog This can be done with making the video layers fade in and out.
DV Studio
Posted: Sun, 31st May 2009, 5:09pm

Post 2 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Here is my Cloning in Clab Tutorial. Sorry it took me so long to remember to post it smile

Better late than never I guess wink
Posted: Sun, 31st May 2009, 8:22pm

Post 3 of 7

TheOutlawAmbulance

Force: 931 | Joined: 16th Dec 2008 | Posts: 938

EffectsLab Pro User VideoWrap User Windows User

Gold Member

Wow! Im glad I could be the first to say congrats! That is an awesome tutorial! Say how do you do that fade in and out thing again because I have Sony Vegas Pro? Also what type of camera is that? Pat yourself on the back! +1! biggrin
Posted: Sun, 31st May 2009, 10:08pm

Post 4 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Rating: +1

Storm Grenade wrote:

Wow! Im glad I could be the first to say congrats! That is an awesome tutorial! Say how do you do that fade in and out thing again because I have Sony Vegas Pro? Also what type of camera is that? Pat yourself on the back! +1! biggrin
Thanks man!

To do the fade in/out:
Unfortunately, I am unfamiliar with Sony Vegas, but in Adobe Premier (which should be relatively similar):
1) Import your 3 or so layers
2) In the NLE cloning version, you will crop the video so that all 3 layers are visable
3) If you want to make individual layers fade in, you can right click the video clip on the timeline and select fade video in and then at a later point in the clip you can select fade video out


4) If you want it to look more like this with the dogs appearing and disappearing, siomply split the individual clips at the desired time and then apply the fade in and out effect to each


By alternating the video splits between layers and applying a fade to each split, it should look like this in the timeline


I hope that helps to answer your question!

Let me know what you end up making! biggrin

Cheers
DV

Edit: Sorry, forgot to answer your question about the camera. It is a Sony HDR-SR12 160GB HDD High Def Camcorder- really good quality, I like it alot! Unfortunately, it isn't sold by Sony anymore (strange as I only ordered it in January 2009)- but you can still get it new from Newegg and amazon. Kinda on the pricey side though...
Posted: Sun, 31st May 2009, 11:52pm

Post 5 of 7

TheOutlawAmbulance

Force: 931 | Joined: 16th Dec 2008 | Posts: 938

EffectsLab Pro User VideoWrap User Windows User

Gold Member

Thanks that really helped!!! How much was the camera? I was leaning towards a Canon Vixia HV30. Oh, and +1!
Posted: Mon, 1st Jun 2009, 12:11am

Post 6 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Storm Grenade wrote:

Thanks that really helped!!! How much was the camera? I was leaning towards a Canon Vixia HV30. Oh, and +1!
Yeah, the HV30 is really good- and it is mini DV- I would go with that one- much easier to use, relatively cheap, and one of the better cameras on the market.

The sony ne was about $999 (a little expensive, but does the job)
Posted: Mon, 1st Jun 2009, 12:25am

Post 7 of 7

TheOutlawAmbulance

Force: 931 | Joined: 16th Dec 2008 | Posts: 938

EffectsLab Pro User VideoWrap User Windows User

Gold Member

Wow! ya....I can see me NOT buying that and while on this subject can you find a new camera with all the accesories it is supposed to come come with relatively new.(I say this because on Ebay sometimes people don't sell the full package just the camcorder its self.)
