CLab Cloning Tutorial

Posted: Sun, 31st May 2009, 5:07pm

Post 1 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Rating: +2

Hello all!

Here is a tutorial that I worked on recently for cloning using FX Home Composite Lab Pro. Hopefully it isn’t too hard to follow or understand and I hope the pictures help to make some of the more confusing looking steps (in writing) easier to understand. PM me if you need help!

What you’ll need

-A pet or someone who wants to be ‘cloned’
-A video camera

-A tripod (a must)

-FX Home Composite Lab Pro


Getting started
Okay, well now that we’ve gathered the materials, I will begin to walk you through the cloning process.
1. You need to find a suitable location to film the effect. Make sure it is in a low traffic area so no one interrupts the shot. For this first time, we will do the effect indoors, although it is very possible for an outside effect.
2. Setting up the camera and tripod. This is the most important step as this needs to be precise. The tiniest camera movement will completely mess the shot up.
3. Get you actor/actress/pet ready for the shot and on screen.
4. Record the video. The best thing to do is to press start and let the camera run until the end of the filming portion of the effect. This is best as you will not accidentally disturb the camera’s position by pressing the record button and will leave the shot steady. (of course, if your camera has a remote control, this is a good alternative option.
5. For this tutorial we moved the subject (the dog) around into 3 different areas of the shot (note: we did not move the camera, just the dog)
6. After the filming is done and you got all the positions you want (again, recorded into 1 scene), press the stop button on the camera

Steps:
1. Open Composite Lab Pro
2. Select ‘select video clip’

3. Select your first video clip (will be layer 1)

4. Open your other video layers (in this case 2 others)

5. Under the settings for video 1 click the drop down arrow under matte and choose garbage matte

6. Choose the square option

7. Drag the edges to cut off the unneeded part of the video (this is where the second overlay will fit in)

8. It will look like this when it is done:

9. Now, drag the second video clip into the screen and repeat the garbage matte process, but place the square matte on the opposite side of the new video clip:

10. It will look like this when you click out:

11. Now drag the third video clip in, and apply another garbage matte to this clip (this matte will be placed above the third clip as to cut out the area the other two clips will take up)[(sorry if that is kind of confusing- the picture will help]

12. When you click out of the garbage matte, this is what you should have so far:

13. Now your cloning effect is finished and you can now fool around with it to adjust lighting, contrast, or add some cool grading effects!
Examples:




Hopefully someone can find that helpful.

Cheers,
DV Studio

P.S. I also wanted to add this link to a video I did a while back with cloning my dog: cloning/disappearing dog This can be done with making the video layers fade in and out using an NLE.

P.P.S. Check out my tutorial on cloning in an NLE here
Posted: Mon, 1st Jun 2009, 9:46am

Post 2 of 7

Simon K Jones

Force: 27955 | Joined: 1st Jan 2002 | Posts: 11683

VisionLab User VideoWrap User PhotoKey 5 Pro User MuzzlePlug User PowerPlug User PhotoKey 3 Plug-in User FXhome Movie Maker FXpreset Maker Windows User

FXhome Team Member

Nice tutorial. A bit of feathering on the masks to disguise the edges would be cool. Also need to watch the lighting and/or camera settings, which seemed to change slightly between shots.
Posted: Tue, 2nd Jun 2009, 8:43pm

Post 3 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Tarn wrote:

Nice tutorial. A bit of feathering on the masks to disguise the edges would be cool. Also need to watch the lighting and/or camera settings, which seemed to change slightly between shots.
Yeah I know. I shot the video quickly before I moved out of my old house and didn't have time to reshoot. Oh well. Thanks for the comments though!
Posted: Tue, 23rd Nov 2010, 2:12am

Post 4 of 7

Azulon'sAssassin

Force: 1108 | Joined: 26th Oct 2010 | Posts: 648

VisionLab User Windows User

Gold Member

Will this work with actuall moving video? I need to clone someone just b/c I don't have enough actors/actresses.
Posted: Tue, 23rd Nov 2010, 3:12am

Post 5 of 7

Axeman

Force: 17995 | Joined: 20th Jan 2002 | Posts: 6124

VisionLab User VideoWrap User PhotoKey 5 Pro User MuzzlePlug User PowerPlug User PhotoKey 3 Plug-in User FXhome Movie Maker FXpreset Maker MacOS User

SuperUser

Yes, he is using video in the tutorial. Its meant to use with video.
Posted: Tue, 23rd Nov 2010, 3:15am

Post 6 of 7

Azulon'sAssassin

Force: 1108 | Joined: 26th Oct 2010 | Posts: 648

VisionLab User Windows User

Gold Member

OH thanks.
Posted: Tue, 30th Nov 2010, 1:56am

Post 7 of 7

DVStudio

Force: 4983 | Joined: 22nd Nov 2007 | Posts: 1845

CompositeLab Pro User EffectsLab Pro User PhotoKey 4 User FXpreset Maker FXhome Movie Maker Windows User

Gold Member

Rating: +1

Wow, this is an old one of my tutorials. Expect something new soon, as in a video walk through of the process. I was looking for a new tutorial idea, so thanks for brining this one up. wink

EDIT: Here's my new Vision Lab cloning tutorial video. It's a pretty simply walkthrough of the process detailed above, and it's in full HD. Let me know what you think- I put this together in just a few minutes over the past two days, but I think it turned out well. wink

And of course, the Linky.
